Customized Professional One-Stop Custom PCB PCBA Board Service for Electronic Devices

Professional One-Stop Custom Oem Pcb Pcba Board Service Manufacturers Electronics Pcb Boards Prototype Pcba Assembly

XZH: Your One-Stop ODM/OEM Solution Provider

Customized Professional One-Stop Custom PCB PCBA Board Service for Electronic Devices

Product Introduction

Base material	FR4,High-TG FR4,CEM3,aluminum, High Frequencey frequency(Rogers,Taconic,Aron,PTFE,F4B)
Layers	1-4 Layers(Alunimum), 1-32 layers(FR4)
Copper Thickness	0.5oz, 1oz, 2oz, 3oz,4oz
Dielectric Thickness	0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
board Core Thickness	0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 3.0mm and 3.2mm
Board Thickness	0.4mm - 4.0mm
Thickness Tolerance	+/-10%
Aluminum Machining	Drilling, Tapping, Milling, Routing, Die-Punching, Break-off tab available
Min Hole	0.2 mm
Min Track Width	0.2mm (8mil)
Min Track Gap	0.2mm (8mil)
Min SMD Pad Pitch	0.2mm (8mil)
Surface Finishing	HASL lead free,ENIG,Plated Gold,Immersion Gold,OSP
Solder Mask Color	Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Legend Color	Black, White etc
Assembly Types	Surface mount Thro-hole Mixed technology (SMT & Thru-hole) Single or double sided placement Conformal coating Shield cover assembly for EMI emission control
Parts Procurement	Full Turnkey Partial Turnkey Kitted/Consigned
Component types	SMT 01005 or larger BGA 0.4mm pitch, POP (Package on Package) WLCSP 0.35mm pitch Hard metric connectors Cable & wire
SMT Parts Presentation	Bulk Cut tape Partial reel Reel Tube Tray
Stencils	Laser-cut stainless steel
Other Techniques	Free DFM Review Box Build Assembly 100% AOI test and X-ray test for BGA IC programming Components cost-down Function test as custom Protection technology

PCB Service

XZH Supply single-side, double –side board, multilayer boards (1-20 layers), Boards type:Rigid PCB(CEM, FR4), Flexible PCB, Rigid-Flex PCB, MCPCB(Aluminum PCB), Ceramic PCB, RF PCB, etc.

PCB Assembly&Components Sourcing

XZH offer Printed Circuit Board Assembly ,components Sourcing and complete solutions. what we can always gurantee is the best quality,competitive price and best service.

More Details or Other requirements welcome to Email and Chat with us.

Company Profile

XZH Technology Co., Ltd. was founded in 2014, with a perfect quality assurance system and advanced test-analyzed instruments. We have rich experience in the production and development of voice recorders and wireless earphone power banks for many years. Our specialty is in PCBA assembly, suitable for computers, audio devices, home electronic devices, and other precision instruments. We have gained the trust of clients in China and abroad. With the mission of 'Customer Priority and Quality Comes First,' we have passed UL, VDE, CQC, CAS, ISO9001, and ISO1400 certifications.

Certifications

Exhibition

Our Advantages

Product Leading Time

	Sample Lead time	Mass production lead time
Single sided PCB	1~3 days	4~7 days
Double sided PCB	2~5 days	7~10 days
Multilayer PCB	7~8 days	10~15 days
PCB Assembly	8~15 days	2~4 weeks
Delivery time	3-7 days	3-7 days
Package: Anti-static Package with carton

FAQ

Q1:Are my design files secure when I send them to you?

A:Your files held in complete safety and security. Your files are never
shared nor will any third parties have access to your design files. Fulltronics can sign a Non-disclosure agreement before sending files.

Q2:For small quantity orders, can you produce prototype PCBs?

A:Yes, XZH PCB can produce prototypes. but the greater the quantity, the greater the cost savings.

Q3:Do you have after-sales product servicing available for your customers?

A:Yes, for any quality problems XZH PCB will take our responsibility to solve them for you at any time. What we can always guarantee is our best service, high quality with competitive price.

Q4:What's files do you need in the PCBA projects?

A:Exclude the pcb file, the PNP(Pick and Place) file and Components Position file also needed.

Q5: Does our product will be tested before shipment?

A: Yes, we could provide Function Circuit Testing if you provide us the testing methods.
