OEM / ODM Multilayer PCB Design Gerber PCB Manufacturing And Assembly

Ask Lasest Price
Model Number :	XZH-PCB
Brand Name :	OEM
Price :	$0.50/pieces 1-9 pieces

Add to Cart

Product Details
Company Profile

OEM / ODM Multilayer PCB Design Gerber PCB Manufacturing And Assembly

OEM Multilayer Pcb Design Gerber Pcb Manufacturing And PCBA Assembly

XZH: Your One-Stop ODM/OEM Solution Provider

OEM / ODM Multilayer PCB Design Gerber PCB Manufacturing And Assembly

Capabiity

Description	Technology & Capabilities
1. Product Range	Rigid PCBs from 2- 24 layers, HDI; Aluminium base
2. Min. Board Thickness	2 layer	4 layer	6 layer	8 layer	10 layer
		min. 0.2 mm	0.4 mm	1 mm	1.2 mm	1.5 mm
		12 & 14 layer	16 layer	18 layer	20 layer	22 & 24 layer
		1.6 mm	1.7 mm	1.8 mm	2.2 mm	2.6 mm
3. Max. Board Size	610 x 1200 mm
4. Base Material	FR-4 Glass Epoxy laminate, Aluminium base, RCC
5. Surface Finish Treatment	Electroless nickel Immersion gold ( Electoless Ni/Au). Organic Solerability Preservatives ( OSP or Entek). Hot Air Leveling ( Lead- Free, RoHS). Carbon Ink. Peelable Mask. Gold Fingers. Immersion Silve. Immersion Tin. Flash gold ( Electrolytic)
6. Major Laminate	King Boad (KB-6150). ShengYi (S1141; S1170). Arion. YGA-1-1; Rogers and others.
7. Via Holes	Copper PTH/ Blind Via/ Buried Via/ HDI 2+N+2 with IVH
8. Copper Foil Thickness	18um/ 35um/ 70um~245um (outer layer 0.5oz~7oz) 18um/ 35um/ 70um~ 210um (inner layer 0.5oz~6oz)
9. Min. Via Size and Type	Dia. 0.15mm (Finished). Aspect Ratiao = 12; HDI holes (＜0.10mm)
10. Min. Line Width & Spacing	0.75 mm/ 0.10mm ( 3mil/ 4mil)
11. Min Via Hole Size & Pad	Via: Dia, 0.2mm/ pad. dia. 0.4mm; HDI＜0.10mm via
12. Impedance I Control Tol.	+/- 10% ( min. +/- 7 Ohm)
13. Solder Mask	Liquid Photo- Image (LPI)
14. Profiling	CNC Routing, V- Cutting, Punching, Push back punching, Connector chamfering
15. Capacity	100 k㎡ output monthly

Want more information or would like to receive a quote? Click the CHAT NOW button at the top right to contact our salespeople.
